Automatic PET Bottle Beer Filling Machine , Energy Drink Production Line

Name: Automatic PET Bottle Beer Filling Machine Energy Drink Production Line
Brand: JINYATE
Price: 1 USD

Automatic PET Bottle Beer Filling Machine , Energy Drink Production Line Manufactures

Brand Name : JINYATE

Model Number : DCGF32-32-10

Certification : ISO CE

Place of Origin : China, mainland

MOQ : 1set

Price : pls inquiry

Supply Ability : 99 sets per year

Delivery Time : 35 working days

Packaging Details : standard wooden cases

product name : carbonated drink bottling machine

machine type : rinser filler capper tri-monobloc

suitable bottle : PET plastic bottle

bottle size : 250-2000ml

filling material : CSD drink, gas liquid

capacity : 12000BPH(500ML)

material : SUS304

Warranty : 1 year

Contact Now

Automatic PET Bottle Beer Filling Machine,Energy Drink Production Line

Production Introduction

1.The filling machine is used in producing all kind contained with polyester bottle.

2.Washing.filling,sealing can be carried out on the same machine.

3.The advanced technology from Germany and Italy are employed.

4.The filling device can be stopped automatically when there is no bottle or bottles are damaged.

5. The bottle outlet starwheel is of screwdown shape. When bottle size is changed, there is no need to adjust the transferring chain’s height.

6.The whole machine is controlled by PLC with touch-screen as the interface between human and machine.The amount of the drinks in the drink tank can be controlled automatically.The filling and capping will be stopped automatically when there is no bottly.

Automatic PET Bottle Beer Filling Machine , Energy Drink Production Line

rinser head

Automatic PET Bottle Beer Filling Machine , Energy Drink Production Line

capper

Automatic PET Bottle Beer Filling Machine , Energy Drink Production Line

Besides this DCGF32-32-10, We also have other capacity

Model	DCGF16-12-6	DCGF18-18-6	DCGF24-24-8	DCGF32-32-10	DCGF40-40-12	DCGF50-50-15
Number of rising heads	16	18	24	32	40	50
Number of filling heads	12	18	24	32	40	50
Number of capping heads	6	6	8	10	12	15
Bottle standard(mm)	Diameter:Φ50-Φ108 Height:150-320
Rated production capacity(500ml)	2000BPH	4000BPH	7000BPH	8000BPH	10000BPH	12000BPH
Installed capacity(KW)	3.8	4.3	6.5	8.7	9.5	12
