Description:
This machine is used to produce glass bottle various juice, which combines ringsing, juice filling, pulp filling and capping four stations in one unit.
Specially the seperate pulp station guarantees the machine can fill big pulp.
Techinial parameter:
| Containers and specifications |
| Project Name: Full Automatic Complete Pulp Juice 2000-24000bph Production Line | PH≥4.6 |
| Material | Shape | Filling volume | Filling level(mm) | Neck type |
| glass Bottle | Square or Round Bottle | 100-2000ml | Distance from bottle neck According request | As request |
| Adjustable specifications of the bottle type | 【Middle Mould Base】Bottle diameter ≤105mm Bottle Height≤335mm |
Customers need to buy additional change-over parts for the different bottles.
If using square bottles, then bottle separating system will be added. |
| Container Label & Control Mode | Packaging system | Palletizing system |
| Hot Melt Roll-Fed PVC Shrink Label Full Label/ Half Label Manual / Automatic | Packing system | Min, Spec. | Manual
Low position gantry palletizer
Robot Palletizer
High position gantry palletizer
Single Arm Palletizer
Manual Palletizer |
Manual
Film shrinker
Wrap Around packer
Robert Packing Machine | 1*2
2*3
3*4
4*6
3*5 |
| User Ambient Conditions | Temperature:10～40℃；Humidity:No dew |
| User Electrical Supply Specification | Voltage:380V±5%, 3phase； Frequency:50HZ±1% |
Machine picture
After sales service
• Find our products through http://www.automatic-bottlefillingmachine.com. One year warranty for the whole system.
• We can send our engineers/technicians for installation of entire production line to your factory.
• After one year , we can help you to maintain the machine and the accessories are provided only at the cost price.
• We can provide internship service and help you train the operator and mechanic.
• Free production technology and process configuration.
• We can help you to design the product line , workshop and provide turn-key project.
We have rich experience in glass bottle juice package machine, can provide complete line plants, capacity starts from 1000 bottles per hour to 30000BPH, also can customize the equipment according to your request, please contact... ...
